Measurement Range : 1,000 / 2,000 / 3,000 mm SWE
Resolution : 0.1 kg/m² ≙ 0,1 mm SWE
Accuracy : 0.3 % (FS)
Measuring Surface : 6.72 m²
Total weight : 130 kg
Dimensions : 2800 x 2400 x 103 (L x W x H mm)
Protection : IP 68
Power source : 10 ... 30 VDC
Power Input : max. 70 mA
Operating temperature : - 40 ... +80 °C
Maximum Slope : 5°
Output : SDI-12, RS-485 (ASCII and MODBUS), 4 ... 20 mA
Other Features : Improved Lightning Protection
