Automatic Reset function at necessary conditions
Power Supply: 8 … 28Volt DC Peak 1,5A
Stand by: 25mA
Power off: 62uA
RS232 Port : 1 unit
Idle (registered, power saving): 1.5mA @ DRX=9
Dedicated mode: <240 mA @ max power level
GPRS class 10: <420 mA @ max power level
TXT Message sending and receiving, sending data
and alarm to the selected e-mail address when
server is active
Output Power:
Class 4 (W) @ 850/900MHz
Class 1 (1W) @ 1800/1900MHz
Control via AT commands according to 3GPP TS
27.005, 27.007 and Telit Custom AT commands
Quad Band EGSM - 850/900/1800/1900MHz
Serial port multiplexer 3GPP TS 27.010
SIM access profile
TCP/IP stack access via AT commands
Sensitivity:
107 dBm (tpy.) @ 850/900MHz
106 dBm (typ.) @ 1800/1900MHz
Extended temperature range
-40 to +80°C (operational)
-40 to +85°C (storage temperature)
Point-to-point mobile originated and mobile
terminated SMS
Concatenated SMS supported
SMS cell broadcast
SMS Text mode
SMS over GPRS
Circuit Switched Data Transmission
GPRS Class 10
Mobile station class B
Coding scheme 1 to 4
Network LED support
Embedded TCP/IP stack, including TCP, IP, UDP,
SMTP, ICMP and FTP protocols
GSM/GPRS Communication
Protection Class: IP65
Compatible with OEL-104, RG-200, PLT-02,
WLR-01 and Mini Logger
Compatible with every GSM line in Turkey
TCP data transmission to the entered address
Can work as Server and Client
Automatic reconnection when identified APN
connection is cut off
Replying Data call feature
